High Stability 4-20mA Output Relative Pressure Sensor For Coffee Machine Pressure Sensor

Place of Origin : Anhui, China

Brand Name : WNK

Model Number : WNK80mA

Packaging Details : each product in one inner paper box with protection

Supply Ability : 2000 Set/Sets per Week

Price : $10.00 - $35.00/Pieces

MOQ : 1pcs

Payment Terms : T/T, Western Union, MoneyGram, Paypal

Delivery Time : 5-8 work days

Certification : CE/ROHS

Warranty : 1 YEAR

Customized support : OEM, ODM

Measured media : liquid, gas and steam

Output signals : 4~20mA, 1-5V, 0-10V, 0.5V-4.5V, I2C

Accuracy : 1%F.S.

Pressure range : 0-60Bar

Protection class : IP65

Housing material : 304SST/316L

Power Supply : 24VDC/12VDC/5VDC/3.3V

Electrical connection : Packard, M12, DIN43650, Cable

Keywords : coffee machine pressure sensor/relative pressure sensor

MOQ : 1Set

Port : Shanghai port

Contact Now

High Stability 4-20mA Output Relative Pressure Sensor For Coffee Machine Pressure Sensor

Mems Assembled 0.5-4.5V 0-10V Relative Pressure Sensor for Coffee Machine
WNK80MA is a series of high performance compact pressure Transmitter, by using ASIC signal conditioning chip and dry ceramic capacitive pressure sensor. It has features of anti-corrosion, anti-wear, shock resistance and vibration resistance. Its anti-overload capacity is up to 100 times of the range, completely solved poor overload in small range of other sensors. In addtion to general ranges of normal sensors, its most outstanding characteristic is the positive and negative gauge pressure function. With high output and wide range, WNK80MA is especially suitable for manufacturing of high-performance industrial control pressure transmitter and harsh environment pressure measurement.

Production Spec

WNK80MA Gauge/Absolute/Sealing Pressure Transmitter
Applicable media	Liquid, Gas
Pressure range	0-7kPa~350bar
Pressure measurment	Gauge Pressure, Absolute pressure, Sealing pressure
Output	4-20mA/0.5-4.5V/1 -5V/0-10V/I2C
Accuracy(linearity,Hysteresis and Repeatability)	0.5%F.S.(Typical)
Power supply	24VDC/12VDC/5VDC/3.3V
Compensation temperature	-20~85ºC
Ambient temperature	-40~125ºC
Working temperature	-40~125ºC
Temperature drift(zero)	±0.15% F.S. (-20~85ºC)
Temperature drift(full range)	±0.15% F.S. (-20~85ºC)
power(electrical) connect	Parkard, M12, DIN43650, Cable outlet
Mechanical connection	G1/4, 1/4NPT, 1/8NPT, M12*1.5, customize
Housing material	304 stainless steel(inner core is 316 stainless steel)
Protection	IP65

Hot Product

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea.
